COLE HERSEE Contura Rocker Switches, 24V

These switches are recommended for replacements in waterproof electrical panels with rocker switches to ensure waterproof integrity.

You’ll find these Contura Rocker Switches from Cole Hersee are suitable for all kinds of general-purpose applications. Weather-resistant with contact areas sealed to IP66 waterproof rating (high pressure wash-resistant) and recognized at UL 1500 (ignition protection for marine products) for use on boat decks. Models with an LED light indicate when the circuit is on.* Several configurations are available for almost any application. Includes both black and gray covers. Both switches and covers are interchangeable with similar switches used as original equipment on many common boat types.

These sealed rocker switches feature a plastic housing, bezel and actuator with silver contacts, brass blade terminals and a neoprene gasket/panel seal. They conveniently snap into a standard rectangular mounting hole of 1 1/2″ x 13/16″ (36.83mm x 21.08mm) in panels from 0.09″ to 0.19″ thick (2.4mm to 4.7mm). Rated at 15A@24V DC (20A@12V DC).

*NOTE: LED indicator lights on those models that have them (see table below) are rated for 24 volts and will only operate at that specified voltage. The switch will operate at 12 volts, but the light will not.

Key Features

• Non-corrosive plastic construction
• Neoprene gasket/panel seal
• Protect against dust and prolonged spray to IP66 standards
• Supplied with black and gray snap-on actuators
• LED bulb illuminates in the ON position

Model	Type	Switch Function	Illuminated	Lens 1 Color	Lens 2 Color	Terminals
7808207	SPST	Momentary ON-OFF	No	n/a	n/a	2 blade
7808215	SPDT	ON-OFF-ON	Yes	Amber	Amber	3 blade
7808223	SPDT	Momentary ON-OFF-Momentary ON	No	n/a	n/a	3 blade
7808231	SPDT	Momentary ON-OFF-ON	Yes	Amber	n/a	3 blade
7808249	SPDT	Momentary ON-OFF-Momentary ON	No	n/a	n/a	3 blade
7808256	DPDT	Momentary ON-OFF-ON	Yes	Amber	n/a	6 blade
7808264	DPDT	ON-OFF-ON	Yes	Amber	Amber	6 blade
7808272	DPDT	Momentary ON-OFF-Momentary ON	No	n/a	n/a	6 blade
7808280	DPST	Momentary ON-OFF	No	n/a	n/a	4 blade
7808298	DPST	ON-OFF	Yes	Amber	n/a	4 blade
