BLUE SEA SYSTEMS 6-Position AC Main/18-Position DC Main, European

A traditional stand-alone metal AC main panel with branch circuits for European use

Blue Sea Systems traditional metal breaker panels have been installed in boats for years. They have become the standard for reliability and design. A wide variety of breaker styles and ratings make these panels an easy choice for most electrical systems.

This panel is best suited as an AC Main panel for boats used in European waters. It comes pre-wired for easy installation with hot, neutral, and safety ground bus bars already installed. Two digital multifunction meters with alarms provide valuable information to stay on top of battery and electrical systems conditions. AC main, DC main, AC branch and DC branch breakers are pre-installed, 12 position are left open for customization or expansion. All breakers combine switching and circuit protection and are trip-free and cannot be held in the ON position when a fault is detected. A red LED reverse polarity indicator light warns if polarity is switched; a not too uncommon situation at dock. A green LED at all positions indicates switch is ON. Large format labels are backlit for visibility in low or no light conditions.

Key Features

• Pre-wired with hot, neutral and ground buses installed
• Traditional aluminum plate structure will match many pre-existing panels
• One 16A A-Series double pole AC main breaker
• Three 8A A-Series single pole AC branch breakers
• One CA1 100A Red IP DC main breaker
• Twelve 15A A-Series single pole DC branch breakers
• Includes two multimeters to monitor system functions
• Trip-free feature prevents breaker from being held in ON position when a fault is detected
•  MIL-C-5541C spec. immersion coating for a lifetime of corrosion resistance
• Red reverse polarity indicator LED
• LED indicator lights note ON position
• Lifetime warranty

Specifications

• Positions: 1 AC main, 6 AC branch, 1 DC main, 18 DC branch
• Voltage:  230V AC
• Switch Rating: 16A AC main, 8A AC branch, 100A DC main, 15A DC branch
• Dimensions: 10″H x 15 3/4″W x 4″D
